11.2.1 Using the Keypad to Program the MR-2300
1. Access the configuration mode as described in section 11.0 above.
2. Press ENTER to select an option.
The corresponding menu appears.
3. Press the up and down arrow buttons to scroll through the menu.
4. Press the left or right arrow buttons to select or unselect an option (selected = X). Use
the up and down arrows to scroll through the different options.
5. Once you have made the correct selection, press ENTER to confirm the change.
6. Press CANCEL to return to the previous menu.
11.3 MR-2300 Config (Command-Menu)
The MR-2300 configuration menu is shown in Figure 39.
Figure 39 MR-2300 Config menu
- Panel Config -
1 Features
2 Inp. Zone
3 i3 Zones
4 Opt. Zone
5 Correlation
6 Inp Zone Label
7 Opt Zone Label
8 Default Config
To Next Page
