11.15.1 Example 1 (detection circuit)
Event 01 of 09, OPEN TRB on initiating circuit Z-01 in the EAST LOBBY ENTRANCE with
process type as VERIFIED ALARM and the event occurred on 2003/02/02 at 18:01
TUESDAY.
Figure 53 Detection circuit zone message
11.15.2 Example 2 (indicating circuit)
Event 02 of 09, SHORT TRB on indicating circuit NAC-01 in the EAST WING LOBBY with
process type as SILENCEABLE and the event occurred on 2003/02/02 at 18:01 TUESDAY.
Figure 54 Indicating circuit zone message
Other common messages are described below.
EAST LOBBY ENTRANCE
OPEN TRB 01/09
VERIFIED ALARM Z-01
18:01 TUE 2003-04-04
ZONE
Message
EVENT
01 of 09
Process
Type
Physical
Zone No.
DATE
TIME
"INFO" Key
EVENT
type
EAST WING LOBBY
SHORT TRB 02/09
SILENCE-ABLE NAC-1
18:01 TUE 2003-02-02
"INFO" Key
ZONE
Message
EVENT
type
EVENT
02 of 09
Process
Type
Physical
Zone No.
DATE
TIME
