Secutron MR-2300T

100
Common Trouble Form C, 1 A max, 28 VDC
Aux Relay Form C, 1 A max, 28 VDC
Testing impedance 2 kȍ ground fault
1 Mȍ open
0.1 ȍ short
Battery Type 24VDC Sealed Lead Acid, 12 AH
Charging capability 1.25 Amp
Protection 10A on board (F1) slow blow micro fuse
Compliance System Model MR-2300 LED Series LED Version Fire Alarm
Control Panel
System Type Local, Auxiliary (using MR-2300-PR), Remote
Protected Premises Station (using MR-2300-PR or
MR-2312-LDR, MR-2312-LDW, MR-2308-LDR or
MR-2308-LDW) Central Station Protected Premises
(using MR-2312-LDR, MR-2312-LDW, MR-2308-
LDR or MR-2308-LDW).
Type of Service A, M, WF, SS
Type of Signaling Non-Coded
Applicable Standards NFPA 70 and 72, UL 864, ULC-S524, ULC- S527,
ULC-S559
Table 18 MR-2300 LED System Modules and Annunciators
MR-2300 LED Series Modules and Annunciators
MR-2312-R12/
MR-2306-R6
Relay Adder Module
Must be connected to a listed power-limited
source of supply.
Contact rating NO / NC / 28VDC per contact / 1A resistive
load max
Current consumption standby 0mA, alarm MR-2312-R12 160mA,
MR-2306-R6 80mA
MR-2300-A Input Class A Converter module standby: 0mA / alarm: 0mA
MR-2300-NC4 Output Class A Converter Module standby: 0mA / alarm: 0mA
MR-2300-NC2 Output Class A Converter module Standby 0mA / alarm 0mA
Table 17 MR-2300 LED Series Specifications (Continued)
MR-2300 LED Fire Control Panel Chassis
