Secutron MR-2300T User Manual

94
Figure 59 Four-wire Power Supply
11.21 Supervised Aux. Supply
The supervised auxiliary supply is supervised for shorts. When a short is detected on
supervised auxiliary supply the power is cut off and a trouble message is generated. Press the
SYSTEM RESET button to restore the power the system. If the short is removed, the panel
returns to normal; otherwise the trouble message remains.
Figure 60 Aux. Power Supply
11.22 City Tie Polarity reversal - MR-2300-PR/ Relay module
The city tie or polarity reversal module is supervised for open and whether or not the MR-
2300-PR is plugged in. The relay module is supervised for whether or not it is plugged in.
If any of the modules are not plugged in, the following trouble message appears:
Note: The trouble code and info is for trained service personnel only.
"IN FO " Key
4Wire Pwr. Supply
short 1/ 1
Trouble Type
EVENT
01 of 01
Trb:0x03 Info:0x0001
00:07 SAT 2000-01-01
DATE
TIME
Trouble code Trouble Info
i
"IN FO " Key
Aux. Power Supply
short 1/ 1
Trouble Type
EVENT
01 of 01
Trb:0x03 Info:0x0001
00:07 SAT 2000-01-01
DATE
TIME
Trouble code Trouble Info
