Secutron MR-2300T User Manual

75
11.4 Config Info (Command-Menu
11.5 Set Time (Command-Menu)
Note: Refer to section 11.2.1 on page 64 for detailed instructions on making menu
selections.
Press the down arrow button to see
more information.
Configuration type shows how the panel was configured.
Factory default means the panel has not been configured;
it is as it came from the factory.
Front Panel means it was configured at the panel.
Serial Port means the configuration was done from a
computer through the serial port.
Modem means the configuration was done remotely
through a modem.
If you upload a job configuration to the panel using the MR-
2300 Configuration Utility, the job name appears on this
screen. The job name can be up to a maximum of 20
characters.
Press the down arrow button for further
information.
If you upload a job to the panel using the MR-2300
Configuration Utility, the technician’s name (ID) appears on
this screen. The technician ID can be up to a maximum of
10 characters.
Press the down arrow button for further
information.
This screen shows the date and time that the configuration
was last changed (if Time and Date have been set at the
panel).
This screen shows the version of the MR-2300
Configuration Utility. It displays 0.0.0.0 if the MR-2300
Configuration Utility was not used.
Note: Refer to section 11.2.1 on page 64 for detailed instructions on making menu
selections.
i
Configuration type:
Factory default
Job Name:
No job loaded
Technician ID:
Unknown
Cfg. Date and Time:
hh:mm day year:mm:dd
Configurator Version
x.x.x.x
i
