Command Menu/MR-2300 Config/Features/
3.Output Circuit Correlation
[X] DISABLE->Default
[ ] ENABLE
Signal correlations
If enabled, the programmed
correlations (see section
11.3.5 on page 72) are effective.
If disabled, the programmed
correlations are ignored and all
the output circuits are correlated
to all the input circuits.
Command Menu/MR-2300 Config/Features/
4.Waterflow/Sprinkler Retard
Operation
[X] DISABLE ->Default
[ ] ENABLE
Retard waterflow and
sprinkler circuit
If disabled, all the initiating
circuits configured as water flow
or sprinkler act as non-verified
alarms. If enabled, retard
operation is performed for
initiating circuits configured as
water flow or sprinkler.
See section 9.7.5 on page 52.
Command Menu/MR-2300 Config/Features/
5.Aux. disconnect, disconnects
Aux Alarm relay and all
programmed relays
[ ] ENABLE
[X] DISABLE->Default
"Aux Disconnect"
disconnects prog. relay
If disabled, only the Auxiliary
Alarm Relay is disconnected
when you press AUXILIARY
DISCONNECT (see section
9.4.6 on page 49).
If enabled, the Auxiliary Alarm
Relay and all correlated relays
are disconnected when you press
AUXILIARY DISCONNECT (see
section 9.4.6 on page 49).
Correlated relays include: MR-
2312-R12/MR-2306-R6 relays
and MR-2312-SR12 relays.
Command Menu/MR-2300 Config/Features/
6.Signal-Silence Inhibit timer
[X] DISABLE->Default
[ ] 10 SEC
[ ] 20 SEC
[ ] 30 SEC
[ ] 1 MIN
Signal silence inhibit
Timer
Use this menu to inhibit the
SIGNAL SILENCE button for a
desired length of time. While this
timer is running, pressing the
SIGNAL SILENCE button has no
effect. See section 9.4.2 on
page 49. According to the
Canadian National Building
Code, this timer should be set to
one minute.
Table 14 Feature Config Menu (Continued)
Feature Default
Name in the
MR-2300
Configuration Utility
Description
Opt. Ckt. Corr.
[X] DISABLE
Waterflow/Sprk. Retd
[X] DISABLE
Sig-Sil. Inhibit Tmr
[X] DISABLE
