− 118 −

④Removethe2screwssecuringthemicroswitchtobereplacedandthenremovetheSW

ADJUSTplateandthetransparentinsulationsheet.

MICROSWITCH

509-6036

PHOTO11.2d

⑤ Thewiresconnectedtotheoldmicroswitchcanbereusedforthenewmicroswitch.Removethe

heatcontractiontubecoveringthesolderedareas,usethesolderingirontomeltthesolder,and

removethewiresfromthemicroswitch.

⑥ Solderthewirestothenewmicroswitch.Checkthewiringdiagramtomakesurethereareno

mistakesinthewiring.Inaddition,useaheatcontractiontubeorotherprotectiontoprevent

short-circuiting.

⑦AttachtheSWADJUSTplateandtheinsulationsheettothenewmicroswitchandsecurethem

with2screws.Besuretoinserttheinsulationsheetbetweentheswitchandtheplate.

⑧ InstalltheSWADJUSTplatewiththenewmicroswitchinthebottomofthesteeringunit.

Adjustthepositionoftheplatesothattherolleronthemicroswitch'sactuatorterminaltouches

thepinthatinterlockswiththepaddleleverwhentheleverisnotbeingmanipulated,andsecure

itwith2screws.

⑨ Connectthewireconnectorsandsecurethewireswithaharnesslug.

⑩Manipulatethepaddlelevertomakesurethemicroswitchesareturningonandoffproperly.

Listenforaclickingsound.Also,makesurethattheswitchdoesnotadheretotheactuatoritself

whenturnedon.

⑪Replacethefrontandrearsteeringcovers.Takecarenottopinchthewiresorovertightenthe

screws.

Notethatthescrewsusedtosecuretheleftandrightsidesofthefrontsteeringcoverhave

differentdimensionsfromtheothers.Checkthedimensionsofthescrewsbeforeinstalling

them.

⑫OntheInputTestscreen,checktomakesurethatthemicroswitchesturnonandoffconsistently

whenthepaddleleversaremanipulated(see10-3B).

INSULATIONSHEET

SWADJUSTPLATE

SCREW(2)

M3×16,w/flat&springwashers
