−25−
④ Install6hexagonalboltsonthepillarsideofthecoinchutetower.Takingcarenottodamage
thewiring,haveonepersonsupportthecoinchutetowerwhileanotherinstallsthebolts.
HEXAGONALBOLT(2),black
M8×50,w/springwasher,flatwasherused
HEXAGONALBOLT(4),black
M8×20,w/springwasher,
flatwasherused
PHOTO6.1c
⑤ Install4hexagonalboltsonthe
bottomofthecoinchutetower.
HEXAGONALBOLT(4),black
M8×20,w/springwasher,flatwasherused
PHOTO6.1d
⑥Unlockthecoinchuteandcashbox
doorsandinstall3hexagonnutson
thebasesideoftheinteriorofthecash
boxdoor.
⑦ Returnthecashboxtoitsoriginal
positionandlockthedoor.
HEXAGONNUT(2)
M6,flat&springwashersused
PHOTO6.1e
