INSTALLINGTHECOINCHUTETOWER,ANDTHEPOP/POPCARD
INSTALLINGTHECOINCHUTETOWER
① First,removethecashboxandthencloseandrelockthecashboxdoor.Accidentsmayoccurif
thedoorisfreetoswingopenorclosed.
② Spreadablanketorothersoftsurface
onthefloornexttowherethecoin
chutetoweristobeinstalled,and
placethecoinchutetowerontop.
PHOTO6.1a
③Pluginthe3wireconnectorslinking
thecoinchutetowerandthebase.
Connecttheconnector(3)
PHOTO6.1b
