Sega AV F-ZERO AX User Manual

−49−
1500mm
1020mm
● Useblanketsorothersoftmaterialstoavoidscratchingthesurfaceof
removedparts.
● Certaintypesoffloorsurfacesmaybecomescratchedduring
disassembly.Checktomakesurethefloorisofanappropriatetype
beforebeginningwork.
Iftheentrywaytotheinstallationlocationistoonarroworlow,followthestepslistedbelowto
disassemblethemachine.
Inthestepslistedbelow,removingthecoinchutetowerwillreducethemachine'swidthto1020
mm.Removingthemonitorboxwillreduceitsheightto1500mm.
Afterdisassemblingthemachineandtransportingitthroughthedoor,reversetheprocedureto
reassembleit.
FIG.8.2
● Inordertoensuresafetyandreliability,useasolid,sturdystepladder
whenperformingtheseoperations.Failuretodosomaycause
personneltoslipandfallorthemachinetotipover.
● Becarefulwhenhandlingpartsmadeofplastic.Handlingtheseparts
carelesslymaydamagethem,andtheresultingshardsandcracks
mayinjurepersonnel.
● Whensecuringplasticpartsinplace,takecarenottomakethescrews
andnutstootight.Doingsomaydamagetheseparts,possibly
resultingininjurytopersonnel.
