⑤ Thelowerlightboxisheldinplaceby4screws.Removethe2screwsonthetopsideand
loosenthe2screwsonthebottomside;thiswillallowthelowerlightboxtoberemoved.
Thefluorescentlampscaneasilybecomebrokenwhileremovingthescrews.Exercisecaution
whileperformingthisoperation.
Loosenthe2screwsonthebottomside.
PHOTO8.2m
⑥ Removethe4hexagonnutsholdingtheroofframeinplace.
PHOTO8.2n
Whenassemblingthecabinet,position
theRoofFrameasclosetothewall
behindaspossiblebeforefixingthe
cabinetinposition.
SCREW(2)
M4×10,w/flat&springwashers
HEXAGONNUT(4)
M8,flat&springwashersused
