Sega AV F-ZERO AX - Output Test

−92−
10 − 3C OUTPUTTEST
●Besuretochecktheareaaroundyoubeforetestingseatmovement
andoperation.Themovingseatmaycollidewithsurroundingobjects.
● SelectingSEATandpushingtheTESTButtonwillcausetheseatto
startmoving.Takecaretoavoidaccidentswhentestingthisdevice.
● Toavoidinjury,firstcheckthatnooneistouchingthesteeringwheel.
SelectOUTPUTTESTandpresstheTESTButton.Afterinitialization
thesteeringwheelwillturn.
● SelectSTEERINGandpresstheTESTButtontomakethesteering
wheelturn.Toavoidinjury,firstmakesurethatnooneistouchingthe
wheel.
OUTPUTTEST
STARTBUTTONOFF(ON)
VIEWCHANGE1OFF(ON)
VIEWCHANGE2OFF(ON)
VIEWCHANGE3OFF(ON)
VIEWCHANGE4OFF(ON)
BOOSTOFF(ON)
STEERING
CENTEROFF(ON)
LEFTOFF(ON)
RIGHTOFF(ON)
SEAT
LOCKOFF(ON)
CENTEROFF(ON)
LEFTOFF(ON)
RIGHTOFF(ON)
->EXIT
SELECTWITHSERVICEBUTTON
ANDPRESSTESTBUTTON
FIG.10.3ca OUTPUTTESTScreen
BOOST
VIEWCHANGE1〜4
STARTBUTTON
STEERING
L/R
FIG.10.3cb
FIG.10.3cc
CENTER
LEFT
RIGHT
SelectingOUTPUTTESTandpressingtheTESTButtonwillcausethenextscreentoinitialize
andload.Thisallowsyoutocheckthestatusofeachoutputdevice.
Thistestshouldbeusedperiodicallytocheckthatthelampsarefunctioningcorrectly.
