ASSEMBLY AND INSTALLATION
1
Conrm that the main switch is at OFF.
● Usethepowersupplyequippedwithanearthleakagebreaker.Useofpower
supplywithoutsuchabreakercouldresultinreifthereisacurrentleakage.
● Haveavailableasecurelygroundedindoorearthterminal.Withoutproper
grounding, customers could be electrocuted and product operations might not
always be stable.
●
Donotexposepowercablesorearth(ground)wiresonthesurface,(oor,
passage,etc.).Ifexposed,thepowercablesandearth(ground)wiresare
susceptible to damage. Damaged cords and wires can cause an electric shock or
shortcircuit.Whereverwiringhasbeenlaidoutonaoorsurface,useawiring
protectioncover.
● Forsafetyreasons,besuretorstconnectthepowercabletotheproduct.Ifthe
powercableisrstconnectedtothepowerplug,anaccidentsuchasanelectric
shock or short circuit may occur.
● Afterlayingoutthepowercableontheoor,besuretoalwaysprotectit.Ifthe
powercableisleftexposed,itcaneasilybedamaged,resultinginelectricalshock.
If grounding has been established with the ground wire inside the power cable, do not
performgroundingwiththeACunitgroundterminal.Conversely,iftheACunitground
terminal has been used for grounding, do not establish ground with the ground wire in
the power cable. Otherwise there could be faulty or erroneous operations.
The AC unit has Power Switch, Circuit Protector, Earth Terminal and the inlet which connects the power cable.
6-4 CONNECTION OF POWER AND GROUND
USE ONLY 250V FUSES
6
NOT USED
FUSE
POWER SWITCH
INLET
(Lan Cable Access)
Main switch on.
AC unit
