COIN SELECTOR
14-3 REMOVING A JAMMED COIN
If the coin does not come out when pressing the return button, open the service door and then open the coin selector
gate. After removing the jammed coin, insert a normal coin and make sure the selector works properly.
14-4 LAMP REPLACEMENT
1
Refer to Steps 1 and 2 of 15-2 "CLEANING THE COIN SELECTOR" and open the coin chute door.
2
Undo the cord clamp and pull out the lamp.
3
Turn the lamp, pull it straight out and replace
it with a new one.
14
CORD CLAMP (1)
LAMP
6.3V 1W
