User Manual
TYPICAL CONNECTIONS
GPS Connection
SMART GPS
SENSOR
GPS SENSOR CABLE
GPS SENSOR CABLE
POWER OUTPUT+ (10-35 Vdc)
GPS RX+
GPS TX+
GND COMMON
RED
GREEN
BROWN
BLACK/YELLOW/SHIELD
PIN
1
2
3
6
GPS
ANTENNA
1
2
3
4
5
6
WIRE COLOR
FUNCTION
GPS on Port 3
Autopilot Connection
EXTERNAL
NMEA
DEVICE
POWER & I/O
POWER SUPPLY
-
+
1
POWER & I/O CABLE
POWER & I/O CABLE
PWR-/GND/COMMON
POWER INPUT+ (10-35 Vdc)
INPUT 1+
COMMON
OUTPUT 1+
BLACK
RED
WHITE
GREEN
YELLOW
PIN
1
2
3
4
6
WIRE COLOR
FUNCTION
+
-
COMMON
TX+
RX+
Autopilot on Port 1
POWER & I/O
POWER SUPPLY
-
+
1
POWER & I/O CABLE
POWER & I/O CABLE
PWR-/GND/COMMON
POWER INPUT+ (10-35 Vdc)
OUTPUT 2+
INPUT 2+
BLACK
RED
GRAY
BROWN
PIN
1
2
5
7
WIRE COLOR
FUNCTION
AUTOPILOT
COMMON
RX+
Autopilot on Port 2
External NMEA Connection
EXTERNAL
NMEA
DEVICE
POWER & I/O
POWER SUPPLY
-
+
1
POWER & I/O CABLE
POWER & I/O CABLE
PWR-/GND/COMMON
POWER INPUT+ (10-35 Vdc)
INPUT 1+
COMMON
OUTPUT 1+
BLACK
RED
WHITE
GREEN
YELLOW
PIN
1
2
3
4
6
WIRE COLOR
FUNCTION
+
-
COMMON
TX+
RX+
External NMEA on Port 1
