58 User Manual
n = 1/2/3 for TM5e/TM5i/T-50.05/T-55.05
n = 1/3 for TM5ce/TM5ci
n = 1/2/3/4/5 for TM7e/TM7i/TM11/T-59.09/T-59.05/T-59.01
n = 1/3/4/5 for TM7ce/TM7ci
C-COM GSM Plus Connection
To connect the modem C-COM to the chart plotter follow the procedure:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"Port 1 Input" + [ENTER] + "C-COM" + [ENTER]
The modem C-COM can be connected also to the Port 2 (except for TM5ce/
TM5ci/TM7ce/TM7ci), Port 3 and Port 4/5 (except for TM5e/TM5i/TM5ce/
TM5ci/T-50.05/T-55.05), in this case select the format on the used port.
NOTE The connection is valid for the C-COM IR and C-COM RS232 too.
Output Sentences
The chart plotter allows customizing the NMEA-0183 sentence transmitted on
each port. Each port can transmit a different set of sentences among: GLL, VTG,
BOD, XTE, BWC, RMA, RMB, RMC, APB, WCV, GGA, HSC, HDG, MWV:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"Port n Output Sentences" + [ENTER]
Where:
n = 1/2/3 for TM5e/TM5i/T-50.05/T-55.05
n = 1/3 for TM5ce/TM5ci
n = 1/2/3/4/5 for TM7e/TM7i/TM11/T-59.09/T-59.05/T-59.01
n = 1/3/4/5 for TM7ce/TM7ci
NMEA-0183 Output Talker ID
The Talker Id is the 2 characters following the “$” char (Start of sentence) in a
NMEA-0183 sentence that identifies the type of instrument that sends the string.
The chart plotter allows selecting one of the following Talker identifier: II (Inte-
grated Instrument); GP (GPS); EC (Electronic Chart System-ECS); RA (Radar
and/or Radar Plotting); SD (Sounder Depth). The selected Talker ID is applied to
all sentences sent by the chart plotter from all Ports.
To select the Talker ID follow the procedure:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"NMEA-0183 Output Talker ID" + [ENTER] + "II/GP/EC/RA/SD" + [ENTER]
TM7e/TM7i/TM7ce/TM7ci/TM11/T-59.09/T-59.05/T-59.01:
External Signal
Sets the External Output:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"External Signal" + [ENTER]
Then choose your preferred setting among External Alarm (when activated, this
pin goes to GND level. It is used to command an external buzzer), External Power
(it is command switch for the Radar. It must be used in conjunction with the Radar
Junction box device) and Off.
Cable Wiring pages
This menu allows you select the Cable Wiring page:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output"+ [ENTER] +
"Cable Wiring" + [ENTER]
Power I/O Cable Wiring
1
: Shows a window containing the Power I/O cable wiring.
Quick Disconnect Cable Wiring
2
: Shows a window containing the quick disconnect bracket cable wiring.
GPS Cable Wiring
3
: Shows a window containing the GPS cable wiring.
To Next Page
