57
User Manual
Radar/FF/Chart/Video : Shows the image from the video camera on a rectangular window, in the left top
corner, with Radar, Fish Finder and Chart.
3.6 ADVANCED OPTIONS MENU
[MENU] + "Advanced Options" + [ENTER]
The Advanced options are arranged in sub-menus.
3.6.1 Input/Output menu
WARNING
After every software upgrade the RAM is cleared and the chart plotter re starts
with the usual default settings. Please go to the Input/output menu and set
the proper input format once again.
TM5e/TM5ce/T-50.05/TM7e/TM7ce/TM11/T-59.09/T-59.05/T-59.01:
GPS Connection
Connects the GPS to the GPS Port (serial Port 3). To choose your preferred
setting follow the procedure:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"Port 3 Input" + [ENTER] + "NMEA-4800-N81-N" + [ENTER]
GPS Setup Menu
To set your preferred configuration for the connected GPS.
Internal GPS
1
: Enables or disables the Internal GPS.
Restart GPS : Restarts all GPS processes. Once executed, the message "Done" is shown.
Diff. Corr. Source : Sets what kind of Differential Correction will be used by the GPS between WAAS and RTCM
(beacon correction).
Navigation Speed : Sets the Navigation Speed among Low Speed, Medium Speed and High Speed.
NOTE
1
AVAILABLE FOR TM5i/TM5ci/T-55.05/TM7i/TM7ci.
TM5ce/TM5ci/TM7ce/TM7ci:
Fish Finder Transmission
The internal Fish Finder is connected directly to the Port 2. To switch the internal
Fish Finder transmission On/Off follow the procedure:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"Fish Finder On/Standby" + [ENTER]
Autopilot Connection
Connect the Autopilot to the serial Port n:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"Port n Output" + [ENTER]. Then choose your preferred setting among the
NMEA available settings NMEA 0183 4800-N81-N, NMEA 0180, NMEA 0180/
CDX) and press [ENTER] to confirm.
Where:
n = 1/2/3 for TM5e/TM5i/T-50.05/T-55.05
n = 1/3 for TM5ce/TM5ci
n = 1/2/3/4/5 for TM7e/TM7i/TM11/T-59.09/T-59.05/T-59.01
n = 1/3/4/5 for TM7ce/TM7ci
External NMEA Connection
Connect the External NMEA to the serial Port n:
[MENU] + "Advanced Options" + [ENTER] + "Input/Output" + [ENTER] +
"Port n Input" + [ENTER]. Then choose your preferred setting among the
NMEA available settings NMEA 1200-N81-N, NMEA 4800-N81-N, NMEA 4800-
N82-N, NMEA 9600-N81-N, NMEA 38400-N81-N and press [ENTER] to confirm.
Where:
