36 User Manual
Place the cursor on the desired Waypoint + [Go To]
TM11/T-59.09/T-59.05:
Place the cursor on the desired Waypoint + [GOTO]
A circle surrounds the Waypoint symbol. A dotted line is shown, connecting the
destination with the ship's position. When the destination is placed, all navigation
data are referred to it.
Deleting destination
If the destination has been placed, to stop the navigation to the Waypoint:
Place the cursor on destination icon + [Stop]
1
NOTE If you press [Next]/[Prev.] (or press [2, Next]/[3, Prev.] for T-59.09) the
destination icon is moved on the next/previous Waypoint in the Route.
Otherwise when the cursor is placed on a generic position on the chart:
[ENTER] + "GOTO" + [ENTER] + [Stop]
1
NOTE If you press [Start] (or press [2, Start] for T-59.09), the destination icon is
moved on the new cursor position.
The symbol that identifies the destination disappears from the screen, but the
Waypoint remains.
NOTE
1
FOR T-59.09, press [1, Stop].
2.4 USING TRACK
A very useful feature of the chart plotter, is the ability to store and display exactly
where the boat has been. This feature, referred to as Tracking, can provide
invaluable information about the effect of tide and wind influence on the boat's
progress as well as giving an indication of the helmsman's performance.
When full storing capacity has been reached, the oldest points are deleted and
overwritten by the newest ones.
Setting up a Track Step
Before you use the Track function, it is important to specify the Track step unit: if
you select Distance, the Track point is placed when the distance from its last
stored position is greater than the defined distance; if Time, the Track point is
placed after the defined time.
[MENU] + "Track" + [ENTER] + "Config" + [ENTER] + "Step Unit" + [ENTER]
T-59.09/T-59.05:
[TRACK] + "Config" + [ENTER] + "Step Unit" + [ENTER]
You can select the Track step Time [1, 5, 10, 30 sec, 1 min] or distance [0.01,
0.05, 0.1, 0.5, 1.0, 2.0, 5.0, 10.0] Nm. Setting a short time/distance interval
between Track points is best suited to navigate within a close or complex environ-
ment, a greater time/distance interval is best suited to a long voyage.
To select the interval at which the Track points are placed.
If you have selected Distance:
[MENU] + "Track" + [ENTER] + "Config" + [ENTER] + "Distance Step" +
[ENTER]
T-59.09/T-59.05:
[TRACK] + "Config" + [ENTER] + "Distance Step" + [ENTER]
If you have selected Time:
[MENU] + "Track" + [ENTER] + "Config" + [ENTER] + "Time Step" + [ENTER]
