101
User Manual
TYPICAL CONNECTIONS
GPS Connection TM5e (External GPS Receiver)
SMART GPS
SENSOR
GPS SENSOR CABLE
GPS SENSOR CABLE
POWER OUTPUT+ (10-35 Vdc)
GPS RX+
GPS TX+
GND COMMON
RED
GREEN
BROWN
BLACK/YELLOW/SHIELD
PIN
1
2
3
6
GPS
ANTENNA
1
2
3
4
5
6
WIRE COLOR
FUNCTION
GPS Connection on Port 3
Autopilot Connection
POWER SUPPLY
-
+
1
POWER
& I/O
COMMON
RX+
AUTOPILOT
1
2
3
4
6
PIN CABLE COLOR FUNCTION
POWER & I/O CABLE
POWER & I/O CABLE
BLACK
RED
WHITE
GREEN
YELLOW
PWR -/GND/COMMON
PWR
+
(10-35 Vdc)
INPUT 1+
COMMON
OUTPUT 1+
Autopilot Connection on Port 1
POWER
& I/O
POWER SUPPLY
-
+
PWR -/GND/COMMON
PWR
+
(10-35 Vdc)
OUTPUT 2+
INPUT 2+
1
2
5
7
BLACK
RED
GRAY
BROWN
POWER & I/O CABLE
POWER & I/O CABLE
PIN CABLE COLOR FUNCTION
1
COMMON
RX+
AUTOPILOT
Autopilot Connection on Port 2
External NMEA Connection
POWER SUPPLY
1
POWER & I/O
-
+
EXTERNAL
NMEA
DEVICE
EXTERNAL
NMEA
DEVICE
COMMON
RX+
+
-
TX+
PWR
-/GND/COMMON
PWR
+
(10-35 Vdc)
INPUT 1+
COMMON
OUTPUT 1+
POWER & I/O CABLE
POWER & I/O CABLE
PIN CABLE COLOR FUNCTION
1
2
3
4
6
BLACK
RED
WHITE
GREEN
YELLOW
External NMEA Connection on Port 1
1
POWER & I/O
COMMON
RX+
TX+
POWER SUPPLY
-
+
EXTERNAL
NMEA
DEVICE
EXTERNAL
NMEA
DEVICE
PWR -/GND/COMMON
PWR +
(10-35 Vdc)
OUTPUT 2+
INPUT 2+
1
2
5
7
BLACK
RED
GRAY
BROWN
POWER & I/O CABLE
POWER & I/O CABLE
PIN CABLE COLOR FUNCTION
External NMEA Connection on Port 2
