Specifications
156 | ADN Digital Conference System
XLR OUT
ADN PS power supply
Output resistance R
OUT
< 100 Ω
Frequency response 20 Hz to 14.5 kHz; −3dB
Output level max. +11 dBu
Nominal level +6 dBu
DHT (at 1 kHz) < 0.02% A-weighted at +7.5 dBu
Signal-to-noise ratio > 80 dB A-weighted at +11 dBu
Dimensions 482.5 x 168 x 100 mm (W x L x D)
Weight approx. 4.6 kg
Nominal input voltage 100 to 240 V~
Mains frequency 50 to 60 Hz
Power consumption 385 W
Output voltage at RJ45
PORT I/II output 1/2 52.8 V
Nominal output current at RJ45
PORT I/II output 1/2
max. 5.25 A in total
max. 1.75 A per output
Output voltage at RJ45 DATA 52,8 V
Nominal output current at RJ45
DATA max. 0,08 A
Temperature range operation: +5°C to +50°C
storage: −25°C to +70°C
Relative humidity operation: 10 to 80%
storage: 10 to 90%
