ADN Digital Conference System | 155
Specifications
Specifications
ADN D1 and ADN C1 conference units
Loudspeaker
Microphone
ADN CU1 central unit
XLR IN
Dimensions
(w/o gooseneck) 185 x 63 x 140 mm (W x H x D)
Weight approx. 700 g
Supply voltage 35 V ... 52.8 V
Power consumption 2 W (w/o reproduction via loudspeakers)
Temperature range operation: +10°C to +40°C
storage: −25°C to +70°C
Relative humidity operation: 10 to 80%
storage: 10 to 90%
Headphone socket 3.5 mm stereo jack socket
Output level at
headphone socket 50 mW/16 Ω
DHT (at 1 kHz) 0.03% at 50 mW/16 Ω
Frequency response 100 Hz to 14.5 kHz
Signal-to-noise ratio > 70 dB(A)
Pick-up pattern super-cardioid
Frequency response 190 Hz to 14.5 kHz
Dimensions 417 x 100 x 345 mm (W x H x D)
Weight approx. 6.5 kg
Nominal input voltage 100 to 240 V~
Mains frequency 50 to 60 Hz
Power consumption 245 W
Output voltage at
RJ45 EtherCAT 52.8 V
Nominal output current max. 1.75 A
Temperature range operation: +5°C to +50°C
storage: −25°C to +70°C
Relative humidity operation: 10 to 80%
storage: 10 to 90%
Input resistance R
IN
> 10 KΩ
Input level max. +18 dBu
min. −18 dBu
Nominal level +7.5 dBu
