Structuring and controlling the conference system
16 | ADN Digital Conference System
Small conference system with simple cabling
For small conference systems with approx. 30-40 conference units, you require one
ADN CU1 central unit for controlling the conference. The conference units are inter-
connected in two cable strings which are directly connected to the central unit.
PORT I
PORT II
ADN CU1
max. 80 m
approx.
2-5 m
52.8 V
>35 V
a
ap
20
1
o
x.
x
2 3
...
max. 40
ADN D1/ADN C1
ADN CU1
approx.
2-5 m
