Specifications
Meter Specifications
Version 1.0 Specifications B-1
Appendix B
This appendix provides meter and ANSI compliant socket specifications.
Meter Specifications
Operating
Table B-1: Operating Conditions
Voltage
120 – 480 (96 – 576) VAC
Current
0 to Class Amperes
Rated Frequency
45 – 65 Hz
Ambient Temperature
25°C ± 5°C (77°F ± 9°F)
Environmental
Table B-2: Environmental Conditions:
Temperature
Storage
Operating
-40°C to +85°C (-40°F to 185°F)
-30°C to +55°C (-22°F to 131°F)
Humidity
0 to 95% RH (non-condensing)
Maximums
Table B-3: Maximums
ANSI C37.90.1
2.5kV, 2500 strikes (Oscillatory)
ANSI/IEEE 62.41
6kV, @1.2/50µs, 10 strikes (High Voltage Line Surge
IEC 61000-4-4
4kV, 2.5kHz repetitive burst for 1 minute (Burst)
ANSI C12.1-2001 sec 4.7.3.1
2.5kV, 60Hz, for 1 minute (Insulation)
Current
120% Class Amperes Continuous
200% Class Amperes 1 Second
Voltage
576 VAC (Phase-to-Phase)
