Meter Specifications Specifications
B-2 Specifications TM-iX0A-0805
Input
Table B-4: Input Specifications
Starting Current
5mA for Class 20
50mA for Class 200
*
Power Supply Burden
120V 2.2W 3.5VA
240V 2.8W 6.6VA
277V 2.4W 6.8VA
Current Circuit Burden
< 0.25 VA per phase at Test Amperes
*
- Input voltage measured phase to Neutral.
Physical Dimensions
Dimensions
A B C D E F G
in 6.45 6.95 5.0 0.91 0.27 0.55 3.31
cm 16.38 17.65 12.80 2.31 0.69 1.40 8.41
Shipping Weight
1 Meter Carton 2.6 lbs 1.2 kg
4 Meter Cartons 10.1 lbs 4.6 kg
96 Meter Pallet 278.4 lbs 126.3 kg
