Doc. 177/5250x
Rev A
4-2
Electrical
Input voltage
Working voltage
limits:
15V to 28.8V
Input protection: Input protected against reverse connection of supply
Maximum current draw 100mA
Output protection
Short-circuit: Protected against short circuit to supply
CAN interface
CAN protocol: CANopen profiles DS301
Physical layer uses ISO11898-2.
Baud rates supported: 1Mbits/s, 500 kbits/s, 250 kbits/s, 125 kbits/s, 100 kbits/s, 50
kbits/s
Control inputs
User interface 3 button keypad input
Isolation
Any terminal to the
case:
TBD
(Gen4:Withstands 2 kV d.c.
Meets EN1175-1:1998 and ISO3691
Complies with IEC-60664
EMC
Radiated emissions: EN12895 (Industrial Trucks – Electromagnetic Compatibility)
EN 55022:1998, 6, class B
EN 12895:2000, 4.1 Emissions. When part of a system with a
motor operating,
FCC Part 15, Radiated Emissions. Meets the standards given in
FCC Part 15, Section 15.109:
Conducted emissions: No mains port, therefore not required
Radiated RF field:
EN 61000-4-3, 5.1 Test Level: user-defined test level of 12 V/m
EN 12895:2000, 4.2 Immunity
EN 61000-4-6, Table 1 – Test Levels
Electrical fast transient: EN 61000-4-4, Table 1 – Test Levels, Level 2
