Configuring the Display

Doc. 177/5250x

Rev. A

6-3

Configuring the Available Screens

Screen List

The display has a set of screens, as detailed in the previous section. Most of these screens

can be enabled or disabled for a particular vehicle or application.

The individual screens are enabled through a display object dictionary item as shown below:

Object Index 0x2805 Description Value

Sub 0 Number of sub indexes 11

Sub 1 System overview 1 = enable, 0 = disable

Sub 2 Vehicle status 1 = enable, 0 = disable

Sub 3 Personalities 1 = enable, 0 = disable

Sub 4 Configuration 1 = enable, 0 = disable

Sub 5 Test 1 = enable, 0 = disable

Sub 6 Fault History 1 = enable, 0 = disable

Sub 7 Unused

Sub 8 Unused

Sub 9 Unused

Sub 10 Backdoor* 1 = enable, 0 = disable

Sub 11 Time to Distance 1 = enable, 0 = disable

*The Backdoor screen is an advanced debug screen intended for Sevcon use only. This

should not normally be enabled.

The new selections will take effect on the next power cycle.
