Screen Item Object Dictionary Locations
There are 10 OD entries which are for configuration of the items that can be displayed on
the screen. These are at location 0x2900 to 0x2909. Each object fully defines one screen item.
Each item has a set of sub-index items which are used to control the appearance of the item.
The exact functionality varies depending on the type of item selected. The template object is
shown below:
Object Index 0x2900
to 0x2909
Description Value
Sub 0 Number of sub index’s 11
Sub 1 Item type
Sub 2 X position
Sub 3 Y position
Sub 4 Associated Data Object
Sub 5 Style Flags
Sub 6 Data 1 – Item specific
Sub 7 Data 2 – Item specific
Sub 8 Data 3 – Item specific
Sub 9 Data 4 – Item specific
Sub 10 Data 5 – Item specific
Sub 11 Data 6 – Item specific
