Doc. 177/5250x
Rev A
9-6
The layout – Date and Time
Date and Time item
Object 0x2907 Value
Sub 1 5
Sub 2 100
Sub 3 85
Sub 4 N/A
Sub 5 0x0000
Sub 6 7
Sub 7 N/A
Sub 8 N/A
Sub 9 N/A
Sub 10 N/A
Sub 11 N/A
Sub 1 (5) for a time and date item, located
at (x,y) location of (100,85).
Sub 5 (0x00) means that the item is
displayed date then time, 2 digits for the
year, and the month in words. The 12 hr
format is set in the configuration screen.
