Doc. 177/5250x
Rev A
6-20
13 ‘N’ highlighted in FNR set
14 ‘R’ highlighted in FNR set
15 Warning level fault icon
16 Inhibit level fault icon
17 Severe level fault icon
If you require different bitmapsfor your application then contact your local Sevcon
representative.
Sub 7, 9, and 11 – Reference value
When displaying multiple bitmaps, reference values are used in conjunction with the bitmap
display logic. (see Sub 5 – style flags)
The reference values are:
Sub 7 = reference value for bitmap 1.
Sub 9 = reference value for bitmap 2.
Sub 11 = reference value for bitmap 3.
