Calibrator Calibrator/Adjustments
______________________________________________________________________________
MillipaK PUMP Controller Manual Page 13 07/11/05
Adjustments
Menus 0 to 12 are primarily used for configuring the system. All the personalities that the system
uses to configure each function are in one of these menus. A brief description of the purpose of
each menu is listed below. For more complete descriptions of each personality refer to the
appropriate section in this manual.
Menu Name Purpose
0 Speed 1 Used to set pump speed for lift accelerator 1.
1 Speed 2 Used to set pump speed for lift accelerator 2.
2 Speed 3 Used to set pump speed for switch input 3.
3 Speed 4 Used to set pump speed for switch input 4.
4 Speed 5 Used to set pump speed for switch input 5.
5 Speed 6 Used to set pump speed for switch input 6.
6 Speed 7 Used to set pump speed for switch input 7.
7 Unused Unused.
8 Creep Speed Used to set creep speed.
9 Ramps Used to set lift and power steer ramp times.
10 Power Steer Used to set-up power steer function.
11 Current Limit
Used to set motor current limit, seat delay and low voltage start
and cut levels.
12 System Set-up
Used to configure the system at a high level. Items to configure
the system I/O and performance are located in here. It is
recommended that items in this menu are configured first before
any of the other personalities. Unlike the personalities in the
other menus, changes to items in this menu do not take affect
until the Keyswitch is recycled.
