Specifications
______________________________________________________________________________
MillipaK PUMP Controller Manual Page 47 07/11/05
Specifications
The following specifications apply to all MillipaK Pump controllers.
Power Configurations
At present the MillipaK PUMP controller is available in the following power configurations:
Housing Armature
(CORE) Small 180A
(CORE) Small 300A
(HP) Large 600A
(HP) Large 450A
All the MillipaK PUMP range of controllers operate from 24-48v batteries.
EMC standards
All MillipaK variants are tested to and conform to EN12895.
Socket B protection
All user connections on socket B are protected against indefinite short circuit to battery minus and
battery positive.
Contactor drive ratings
All contactor drives are rated at 3A peak (10s) and 1.5A continuous. All the drives have reverse
battery connection protection, inbuilt freewheel diode and are internally protected against short
circuit.
Analogue Input Impedance
The two analogue inputs are internally pulled up to +12v via a 12k resistor. This is primarily
designed for use with 5k potentiometers, but may also be used with suitable voltage sources.
Digital Input Impedance
The digital inputs are internally pulled up and are active LOW. They therefore must be connected
to battery minus to operate a function. Maximum resistance to battery minus to operate is
500ohms.
