Controller Protection Controller Protection/Under-voltage protection
______________________________________________________________________________
MillipaK PUMP Controller Manual Page 38 07/11/05
Under-voltage protection
In order to prevent a sudden loss in power, the controller will begin to linearly ramp down the
current limit, once the average battery voltage falls below a pre-set under-voltage start level. The
current will be ramped down to 0 and a 7 flash fault indicated if the averaged battery voltage falls
below the under-voltage cut-out level.
Nominal Battery
Voltage
Under-voltage
Cutout
Under-Voltage Start
(adjustable)
24 V 14.5V
36 V 14.5V
48 V 14.5V
Under Voltage Cut-
out up to System V
The following calibrator menu items are used to set these values.
Immediate Low Voltage Start
Calibrator Menu Reference:
11.03
Minimum Maximum Step Size Typical Value
Low V
Cutout
System
Voltage
0.5V 18.0V
Immediate Low Voltage Cutout
Calibrator Menu Reference:
11.04
Minimum Maximum Step Size Typical Value
14.5V Low V Start
0.5V 16.0V
