SEW-Eurodrive MOVIMOT flexible MMF1 C/DBC Series - Page 144

6
Startup
DIP switch
Operating Instructions – MOVIMOT
®
flexible
144
6.5.2 Description of the DIP switches
DIP switch S1/1: Direction of rotation reversal
INFORMATION
The direction of rotation is reversed depending on the setting of the DIP switch and of
the parameter drive train 1 > Controller > Direction of rotation reversal. If both set-
tings are active, the speed setpoint is not inverted (logical XOR).
You can reverse the direction of rotation of the drive using this DIP switch.
• OFF (S1/1=OFF): The drive turns clockwise for a positive setpoint and counter-
clockwise for a negative setpoint.
• ON (S1/1 = ON): The drive turns counterclockwise for a positive setpoint and
clockwise for a negative setpoint.
DIP switch S1/2: Releasing the brake / deactivating DynaStop
®
with FCB01 – enable
WARNING
Risk from falling loads.
This can result in severe or fatal injuries.
• Do not enable the function "Releasing the brake / deactivating DynaStop
®
" for
hoist applications and applications with potentially falling loads.
INFORMATION
If the function of this DIP switch is deactivated via parameter access, the last active
setting of the relevant parameter is maintained.
Use this DIP switch to enable the function "Releasing the brake / deactivating
DynaStop
®
with FCB01" even when the drive is disabled.
• OFF (S1/2 = OFF): The function "Releasing the brake / deactivating DynaStop
®
with FCB01" is inhibited.
• ON(S1/2=ON): The function "Releasing the brake / deactivating DynaStop
®
with
FCB01" is enabled.
When the function block FCB01 is active, you can release the brake or deactivate
DynaStop
®
using a digital input or an actuated process data bit.
INFORMATION
For more information about disabling DynaStop
®
without drive enable, refer to
chapter "Operation".
29129451/EN – 12/2019
