5
Electrical installation
PC connection
Operating Instructions – MOVIMOT
®
flexible
124
5.13 PC connection
Connect the PC to the drive unit before you start the engineering software
MOVISUITE
®
.
You have several options to connect a PC to the device.
5.13.1 Connection via interface adapter USM21A
The USM21A interface adapter is used to connect the PC and the engineering inter-
face of the device.
The data is transferred according to the USB 2.0 standard. It is also possible to work
with a USB 3.0 interface.
You need the following components for the connection:
Component Part number
USM21A interface adapter
The following connection cables are included in the delivery:
• USB 2.0 connection cable
– USB type A/USB type B,
– Length: 1.5m
• RJ10/RJ10 connection cable
For connection to the engineering interface X31
– With 2 RJ10 plug connectors
– Length: 3m
28231449
Connection cable RJ10/M12
For connection to the X4141 engineering interface or to the M12 op-
tional engineering interface at the MMF3... front module:
• With RJ10 plug connector
• With M12 plug connector, 5-pin, male, A-coded
• Length: 3m
28111680
RJ10/SUB-D9 connection cable
For connection to the SUB-D9 optional engineering interface at the
front module of MOVIMOT
®
flexible MMF3...2.. or MMF3...3..:
• With RJ10 plug connector
• With Sub-D9 plug connector, female
• Length: 1.5m
18123864
Retrofit set M12 engineering interface X4141 28258185
29129451/EN – 12/2019
