Device structure
Examples for the optional nameplate "Plug connector positions"
Operating Instructions – MOVIMOT
®
flexible
21
3.6 Examples for the optional nameplate "Plug connector positions"
3.6.1 Design MMF1.
The following figure shows an example of the optional nameplate "Plug connector pos-
itions":
S0#:
X1203_2
X4141
X1203_1
X5504
X5505
01.7659637451.0001.19
18014424412268555
The nameplate shows the designations and positions of the plug connectors at the
connection box. This nameplate can be installed in position 2.
S0#:
X1203_2
X2101
X4141
X1203_1
X5504
X5505
01.1862591901.0001.18
X
3
2
2
29320599051
29129451/EN – 12/2019
