3
Device structure
Examples for the optional nameplate "Plug connector positions"
Operating Instructions – MOVIMOT
®
flexible
22
3.6.2 Design MMF3.
The following figure shows an example of the optional nameplate "Plug connector pos-
itions":
30580203403
The nameplate shows the designations and positions of the plug connectors at the
connection box. This nameplate can be installed in position 2.
S0#:
X2101
X5505
X5504
X1523
X2313
X1203_2
X1203_1
01.1862591901.0001.18
X
3
2
2
29321051275
29129451/EN – 12/2019
