SEW-Eurodrive MOVIMOT flexible MMF1 C/DBC Series - 11.12 Dimension Drawings of Plug Connectors in the Electronics Cover

11
Technical data and dimension sheets
Dimension drawings of plug connectors in the electronics cover
Operating Instructions – MOVIMOT
®
flexible
336
11.12 Dimension drawings of plug connectors in the electronics cover
The following figure shows the additional dimensions of the plug connector.
10
[1]
9007229877298059
[1] M12 plug connector, female
