Startup
Detailed motor selection table for startup via DIP switch S3
Operating Instructions – MOVIMOT
®
flexible
154
Motor Electronics cover DIP switch S3
Motor type Brake Type des-
ignation
Nominal out-
put current
Connec-
tion type
Motor assignment in rela-
tion to the inverter power
Type/nom-
inal voltage
S3/1 S3/2 S3/3 S3/4 Motor power
DRN90S4
0020 2.0A
W 0
m 1
BE2B/230V 0
0025 2.5A
W 0
m 1
0032 3.2A
W 0 0 0 Adjusted
m 1
BE1C/230V 1
0040 4.0A
W 0 1 0 1 stage smaller
m 1 0 0 Adjusted
0055 5.5A
W 0 0 1 2 stages smaller
m 1 1 0 1 stage smaller
DRN90L4
0020 2.0A
W 0
m 1
BE2B/230V 0
0025 2.5A
W 0
m 1
0032 3.2A
W 0
m 1
BE1C/230V 1
0040 4.0A
W 0 0 0 Adjusted
m 1
0055 5.5A
W 0 1 0 1 stage smaller
m 1 0 0 Adjusted
DRN100LS4
(50Hz)
DRN100LM4
(60Hz and
50/60Hz)
0020 2.0A
W 0
m 1
BE5A/230V 0
0025 2.5A
W 0
m 1
0032 3.2A
W 0
m 1
BE2B/230V 1
0040 4.0A
W 0
m 1
0055 5.5A
W 0 0 0 Adjusted
m 1
The motor cannot be started up using DIP switch S3. MOVISUITE
®
or CBG.. is required for
startup.
