SEW-Eurodrive MOVIMOT flexible MMF1 C/DBC Series User Manual

3
Device structure
Example nameplate and type designation
Operating Instructions – MOVIMOT
®
flexible
19
3.5.2 Type designation
The following table shows the type designation of MOVIMOT
®
flexible MMF31S02-
D11-5D3-SFCO0-C/DSP/DFC20A-0020 as an example:
MMF product family
MMF = MOVIMOT
®
flexible
3 Design
1= device variant1
3= device variant3
1 Flange dimensions for relevant electronics cover size
1 = Suitable for electronics cover size1 with or without cooling fins
S0 Mechanics design
S0= housing with metric threads for cable entry
2 Front module
0= Closed
1= Engineering interface M12
1)
2= Prepared for CBG
1)
keypad
3= Prepared for CBG
1)
local operator panel
–
D11 Maintenance switch
000 = Without switching element
D11 = Switch disconnector with feedback contact
1)
M11 = Switch disconnector with feedback contact and line protection
1)
–
5 Connection voltage
5= AC500V
D Power section design EMC
D= EMC filter with limit value category C3 (EN61800-3)
3 Connection type
3= 3-phase
–
BA Connection unit
BA= Connection unit binary or AS-Interface
CO Digital interface (MOVILINK
®
DDI)
DI= Integrated MOVILINK
®
DDI slave (for motors without digital interface)
CO= MOVILINK
®
DDI interface via coaxial cable (for motors with digital interface)
0 Board design
0= standard connection board
–
29129451/EN – 12/2019
