8
Service
Description of status and operating displays
Operating Instructions – MOVIMOT
®
flexible
197
LED Operating status/ Meaning Measure
Fault
code
Subfault code
Red
Flashes 1Hz
3 1 Ground fault Consult the “Fault
table” chapter for
possible measures
to be taken.
4 1 Brake chopper fault
6 1 Line fault
7 1 DC link fault
8 1, 2, 3 Speed monitoring fault
9 1, 2, 5, 6, 9, 10 Control mode fault
10 1, 3–11 Data Flexibility fault
11 1–6 Temperature monitoring fault
12 1, 2 Brake fault
13 5, 24 Encoder 1 fault
16 5–8, 10, 20–27 Startup fault
19 1–9 Process data fault
20 2, 11 Device monitoring fault
23 4 Power section fault
25 2–7, 20, 21, 30, 31,
61, 70
Parameter memory monitoring
26 1, 3 External fault
28 1–12, 14 FCB drive function fault
29 1–4 Hardware limit switch fault
30 1–3 Software limit switch fault
31 1–4, 7, 9 Thermal motor protection fault
32 2–6, 12 Communication fault
33 11, 12, 13 System initialization fault
34 1 Process data configuration
fault
35 1–5 Function activation fault
42 1–3 Lag fault
44 2, 3, 4 Fault
overcurrent phase U, V, W
46 2, 3, 50, 51, 52 Safety card fault
51 1 Analog processing fault
29129451/EN – 12/2019
