Project planning
Motor/inverter assignments
Operating Instructions – MOVIMOT
®
flexible
283
CMP40 – CMP112, 400 V system voltage
n
N
Motor M
0
I
0
M
pk
I
max
M
0VR
I
0VR
m J
mot
min
-1
Nm A Nm A Nm A kg 10
-4
kgm
2
2000 CMP71S 6.4 3.4 19.2 17 8.7 4.6 7 3.04
CMP71M 9.4 5 30.8 26 13.7 7.3 8.4 4.08
CMP80S 13.4 6.9 42.1 33 18.7 9.5 12.8 8.78
3000 CMP40S 0.5 1.2 1.9 6.1 – – 1.3 0.1
CMP40M 0.8 0.95 3.8 6.0 – – 1.6 0.15
CMP50S 1.3 0.96 5.2 5.1 1.7 1.25 2.3 0.42
CMP50M 2.4 1.68 10.3 9.6 3.5 2.45 3.3 0.67
CMP50L 3.3 2.2 15.4 13.6 4.8 3.2 4.1 0.92
CMP63S 2.9 2.15 11.1 12.9 4 3 4.0 1.15
CMP63M 5.3 3.6 21.4 21.6 7.5 5.1 5.7 1.92
CMP63L 7.1 4.95 30.4 29.7 10.3 7.2 7.5 2.69
CMP71S 6.4 4.9 19.2 25 8.7 6.7 7 3.04
4500 CMP40S 0.5 1.2 1.9 6.1 – – 1.3 0.1
CMP40M 0.8 0.95 3.8 6.0 – – 1.6 0.15
CMP50S 1.3 1.32 5.2 7.0 1.7 1.7 2.3 0.42
CMP50M 2.4 2.3 10.3 13.1 3.5 3.35 3.3 0.67
CMP50L 3.3 3.15 15.4 19.5 4.8 4.6 4.1 0.92
CMP63S 2.9 3.05 11.1 18.3 4 4.2 4.0 1.15
CMP63M 5.3 5.4 21.4 32.4 7.5 7.6 5.7 1.92
CMP71S 6.4 7.3 19.2 38 8.7 9.9 7 3.04
6000 CMP40S 0.5 1.2 1.9 6.1 – – 1.3 0.1
CMP40M 0.8 1.1 3.8 6.9 – – 1.6 0.15
CMP50S 1.3 1.7 5.2 9.0 1.7 2.2 2.3 0.42
CMP50M 2.4 3 10.3 17.1 3.5 4.4 3.3 0.67
CMP50L 3.3 4.2 15.4 26 4.8 6.1 4.1 0.92
CMP63S 2.9 3.9 11.1 23.4 4 5.4 4.0 1.15
CMP63L 7.1 9.3 30.4 55.8 10.3 13.5 7.5 2.69
CMP71S 6.4 9.6 19.2 50 8.7 13.1 7 3.04
