Project planning
Motor/inverter assignments
Operating Instructions – MOVIMOT
®
flexible
288
MOVIMOT
®
flexible – 400 V, rated speed 3000 min
-1
, f
PWM
= 8 kHz, non-ventilated
Inverter 0020 0025 0032 0040 0055
I
N
A 2 2.5 3.2 4 5.5
I
max
A 6 7.5 9.6 12 16.5
Motor
CMP40S M
pk
Nm 1.89 1.9
n
N
min
-1
4157 4124
I
max
% 300 242
CMP40M M
pk
Nm 3.8
n
N
min
-1
937
I
max
% 298
CMP50S M
pk
Nm 5.2
n
N
min
-1
713
I
max
% 256
CMP50M M
pk
Nm 7.56 8.88 10.3
n
N
min
-1
1795 1468 1069
I
max
% 300 300 299
CMP50L M
pk
Nm 8.51 10.3 12.4 14.4 15.4
n
N
min
-1
2067 1775 1437 1107 908
I
max
% 300 300 300 300 246
CMP63S M
pk
Nm 7.08 8.27 9.61 10.8 11.1
n
N
min
-1
2179 1834 1578 1280 1174
I
max
% 300 300 300 300 235
CMP63M M
pk
Nm 10.5 12.8 15.2 18.7
n
N
min
-1
2451 2173 1915 1550
I
max
% 300 300 300 300
CMP63L M
pk
Nm 13.4 16.2 20.9
n
N
min
-1
2750 2504 2132
I
max
% 300 300 300
CMP71S M
pk
Nm 11.7 13.8 16.7
n
N
min
-1
2415 2217 1993
I
max
% 300 300 300
CMP71M M
pk
Nm 19.1
n
N
min
-1
2328
I
max
% 300
29129451/EN – 12/2019
