Project planning
Motor/inverter assignments
Operating Instructions – MOVIMOT
®
flexible
290
MOVIMOT
®
flexible – 400 V, rated speed 6000 min
-1
, f
PWM
= 8 kHz, non-ventilated (in preparation)
Inverter 0020 0025 0032 0040 0055
I
N
A 2 2.5 3.2 4 5.5
I
max
A 6 7.5 9.6 12 16.5
Motor
CMP40S M
pk
Nm 1.89 1.9
n
N
min
-1
4157 4124
I
max
% 300 242
CMP40M M
pk
Nm 3.51 3.8
n
N
min
-1
2089 1629
I
max
% 300 277
CMP50S M
pk
Nm 3.97 4.63 5.2
n
N
min
-1
3710 3204 2766
I
max
% 300 300 285
CMP50M M
pk
Nm 4.64 5.65 6.93 8.22 10.1
n
N
min
-1
5077 4645 4131 3658 2998
I
max
% 300 300 300 300 300
CMP50L M
pk
Nm 5.77 7.23 8.79 11.4
n
N
min
-1
5513 5053 4593 3914
I
max
% 300 300 300 300
CMP63S M
pk
Nm 5.33 6.48 7.63 9.36
n
N
min
-1
5145 4634 4161 3517
I
max
% 300 300 300 300
CMP63M M
pk
Nm 9 11.7
n
N
min
-1
5464 4862
I
max
% 300 300
CMP63L M
pk
Nm 12.3
n
N
min
-1
5646
I
max
% 300
CMP71S M
pk
Nm 10.6
n
N
min
-1
5102
I
max
% 300
29129451/EN – 12/2019
