4
Mechanical installation
Mounting the unit
Operating Instructions – MOVIMOT
®
flexible
37
4.6.2 Design MMF3.
The following figure shows the mounting dimensions for the device:
159
312
M6
M6
25829932299
29129451/EN – 12/2019
