Electrical installation
Cable routing and cable shielding
Operating Instructions – MOVIMOT
®
flexible
71
Other connections
Design MMF1.
The following figure shows the connections of the device without motor connection:
INFORMATION
Motor connection is shown in another figure, see chapter "Cable routing and cable
shielding" > "Installation with separately routed Ethernet cable" > "Motor connec-
tion...".
D C B A1 T2 U V W
Supply system
Supply system
STO STO
BR
Binary
30720281227
29129451/EN – 12/2019
