5
Electrical installation
Plug connectors
Operating Instructions – MOVIMOT
®
flexible
78
Plug connector Not together at a
position with the
plug connector:
Designation Coding ring/
color
Function Position
X1203_1 Black AC400V connection
1)
X, 2 or 3
• X1206
X1203_2 Black AC400V connection X, 2 or 3
• X5136
• X2242
X1206 – AC 400V connection (IN)
2)
X, 2 or 3
• X1203_1
X2242 – AC 400V connection (OUT) X, 2 or 3
• X5136
• X1203_2
X2041 Brown Connection for motors without digital
interface
3
• X2104
X2104 None Connection for motors with digital in-
terface (MOVILINK
®
DDI)
3
• X2041
X5136 None Digital inputs/outputs X, 2 or 3
• X1203_2
• X2242
1) Plug connector X1203_1 can also be ordered individually (i.e. without plug connector X1203_2).
2) Plug connector X1206 can be ordered separately (i.e. without plug connector X2242).
29129451/EN – 12/2019
