Electrical installation
Assignment of the optional plug connectors
Operating Instructions – MOVIMOT
®
flexible
99
5.11.3 X5505: STO (3 cores)
WARNING
Disabling of the safety-related disconnection of further devices due to parasitic
voltages when using an STO jumper plug.
Severe or fatal injuries.
• Only use the STO jumper plug when all incoming and outgoing STO connections
have been removed from the device.
The following table shows information about this connection:
Function
Connection for safe torque off (STO, 3cores)
Connection type
M12, 5‑pin, male, A‑coded, color: yellow
Connection diagram
2
1
5
4
3
Assignment
Contact Signal Description
1 Res. Reserved
2 F_STO_P2 F_STO_P2 connection
3 Res. Reserved
4 F_STO_P1 F_STO_P1 connection
5 F_STO_M F_STO_M connection
