SGM Q8 - POI Fixture Installation; Identification and Terminology

13
Product Version 1.0 | Revision D | Released 2022-06-20
INSTALLATION POI FIXTURE
IDENTIFICATION AND TERMINOLOGY
Illustrations might vary from received products. This is subject to change without notice.
B
A
A: RGBW LED panel
B: POI Tilt Lock
C: Cooling Fans
D:
LED Indicator (POI only)
E: Rubber feet
F: GORE-TEX Membrane
G: Power in and out
H: DMX in and out
I: Handle
J: Barndoors attachment points (x2)
K: Safety wire attachment point
L: Holes for Omega brackets / M-10 screws (x6)
C
H
G
K
L
F
D
I
J
E
C
