Product Version 1.0 | Revision D | Released 2022-06-20
SGM VACUUM TEST KIT
The Vacuum Test Kit is an accessory suitable for all SGM IP-rated
fixtures, made for testing the IP integrity upon reassembly.
In order to ensure the IP-rating of the fixture, it’s highly recom-
mended that the fixture is always vacuum tested after installing or
swapping any part that might compromise the IP-rating, e.g.,
swapping the front lens.
SGM disclaims liability for any damage occasioned by the non-use,
or inability to use, the vacuum test kit after reassembling the fix-
ture.
USB XLR UPLOADER CABLE
The SGM USB to DMX cable is an accessory used mainly to update
the fixture with the latest SGM firmware. See below how to update
the fixture with the latest firmware.
The SGM Uploader cable is also used for controlling the DMX val-
ues channel by channel through the Firmware Uploader Tool soft-
ware (available for download at www.sgmlight.com).
Figure 28: SGM Vacuum Test Kit
Figure 29: SGM Uploader Cable
MAINTENANCE
USB POI UPLOADER CABLE
The SGM USB to DMX cable is an accessory used mainly to update
the fixture with the latest SGM firmware. See below how to update
the fixture with the latest firmware.
The SGM Uploader cable is also used for controlling the DMX val-
ues channel by channel through the Firmware Uploader Tool soft-
ware (available for download at www.sgmlight.com).
Figure 30: SGM Uploader cable POI
