19
Product Version 1.0 | Revision D | Released 2022-06-20
FLAT BRACKET ATTACHMENT
OMEGA BRACKET ATTACHMENT
M10 Countersunk Bolts
Flat Bracket
8mm or smaller screw
or bolt to structure
8mm or smaller screw
or bolt to structure
Fixture
13mm / 0.5in hole diameter
for attachment point
M10 Stainless Steel Bolts
POI Omega Bracket
Fixture
